Robot protective system-intelligent climate controlling

Introduzione al prodotto:

The patented product is composed of protective clothing, temperature control system, ventilation pipe and pressure system. The clothing adopts multi-layer structure to ensure the heat insulation effect; the control system can be connected with the communication system of the robot.

The applicable ambient temperature range is - 40 —— 70 ℃， with intelligent temperature regulation, remote monitoring, anti leakage protection and other functions.

It can be used in the cold storage of aquatic products, low temperature preservation, pharmaceutical factories, cold areas in the north, tropical areas and other extreme high and low temperature environments.

Punto dolore dell'utente:

Problemi esistenti: bassa temperatura estrema, alta temperatura estrema, solidificazione lubrificante, surriscaldamento motore;

Perdita dell'utente: arresto del robot, guasto dell'attrezzatura, danno del motore, linea giù;

Parametri materiali:

mported high temperature resistant coating materials:

The material is cold resistant and heat-resistant, with the B1 level of fire resistance; it has good bending resistance, good flexibility in harsh environment, and is not easy to wear out. Combined with the insulation layer, the outer layer has high strength and the inner layer has good heat storage performance.

Flame retardant elastic belt:

Ha buona ritardanza di fiamma, alta resistenza, rapporto di allungamento sopra 1: 2,5 e non è facile produrre fatica sotto l'azione a lungo termine della forza esterna.

Temperature control system:

There are cooling mode, heating mode, water removal mode, etc. In order to realize the function of temperature control, it is necessary to heat up in low temperature environment and cool down in high temperature environment.

Ventilating duct:

Buona flessibilità a bassa temperatura, resistenza all'usura, resistività superficiale inferiore a 10 ^ 9 Ω, nessun inquinamento.

Vantaggi del prodotto:

Heat-resisting

Cold-resistant

Insulation

Ventilation

Industria applicativa:

Climate simulation,Cold storage,Low temperatur,Pharmaceutical,Metalworking,Smelting industry,Spare parts

Vantaggio progettuale:

Digital remote design,No field measurement required,Short supply cycle,High precision design,Only 2D & 3D digital analog, on-site video and pipeline trend are required.

Dettagli del prodotto:

Base pendulum:A large skirt is arranged at the place with a large movement amplitude of the first axis, so that the space increases after inflation and does not interfere with the operation of the robot.

Elastic structure at connecting rod:The lateral elastic ring binds the protective clothing to avoid excessive expansion due to internal air pressure.

Pipeline hanging buckle:A pipeline hanging buckle is added at the lower end of the arm to facilitate the fixation of the pipeline.

Six axis end closure:The protective clothing is fixed on the robot by the double closing way of elastic belt and tie belt to prevent the exchange of internal and external gas from affecting the temperature control effect.

Effetto protettivo:

High quality + safety Escort + intimate service = spring rain protection
